P/N 06-236530-001 3-89 August 2013
3-2.5.2.5.11 How to De-Activate Control-Unit-Based Outputs
Purpose: To manually de-activate control-unit outputs that were
activated during system testing.
CAUTION
There is no indication at the control unit that an output is activated. Be sure to
de-activate the output after proper operation has been confirmed.
Ensure that the outputs will not activate suppression systems or critical facility
operations such as computer power. Physically disconnect all agent-release and
pre-action-sprinkler circuits and bypass all affected power-off circuits before
activating any outputs if the outputs are activating suppression systems or are
shutting off power. Restore the system to normal operating condition at the
conclusion of all output activation and any other functional tests.
Step Action Result
1 Press 0 Key Initiate Menu Access
2 Enter Password; press "Enter" Key Gain access to menus
3 Press 4 Key Enter Test-Menu branch
4 Press "Scroll" Key Access additional Test-Menu options
5 Press 7 Key Select "Output Test" option
6 Press 1 Key for NAC 1, or
Press 2 Key for NAC 2, or
Press 3 Key for Combo 1, or
Press 4 Key for Combo 2, or
Press 5 Key for Release 2, or
Press 6 Key for Release 2, or
Press 7 Key for Relays, or
Press 8 Key for SLC Outputs, or
Press 9 Key for RRM Group
Specify output to de-activate
6a Press 1 Key for Relay 1, or
Press 2 Key for Relay 2, or
Press 3 Key for Relay 3, or
Press 4 Key for Trouble Relay
(if Relays selected in Step 6)
Specify relay to de-activate
7 Press 0 Key and then press "Enter" Key Initiate output de-activation specified in Step 6
and 6a
8 Return to Step 6 and make another selection
(optional)
De-activate additional outputs
9 Press "Backspace" Key (as required) Exit Menu System
