The following actions also occur when a control unit is configured as Group 0 or when the
alarm-verification event is either from another control unit in the same group as the
control unit or from any other control unit in a network configured for global operation.
1. The internal buzzer pulses
2. The alarm-verification event is stored in the event log
3. The alarm-verification message is transmitted to peripheral devices such as RDCMs,
if applicable
4. The alarm-verification message is communicated via the NIC and RS-232 ports, as
applicable
Refer to Paragraph 3-2.5.5.4 for what to do when a remote alarm-verification message
is received.
Note: The time remaining on the alarm-verification timer will only appear on the display
of the control unit that received the verification report from the smoke detector.
Remote, networked control units will not display the alarm-verification timer.
3-3.18 Remote Supervisory Events
Remote supervisory events from a networked control unit are shown in the upper line of
the LCD display by:
•Node-of-origin
• Device address
• State change
•Device type
The lower line indicates the up-to-40-character message assigned to the device using the
ARIES configuration program.
Figure 3-65. Typical Remote Supervisory Message Display
The following actions also occur when the control unit is configured as Group 0 or when
the supervisory event is either from another control unit in the same group as the control
unit or from any other control unit in a network configured for global operation.
1. The Supervisory LED on the display flashes
2. The internal buzzer pulses
3. The supervisory event is stored in the event log
4. The supervisory message is transmitted to peripheral devices such as RDCMs and
ATM-Ls, if applicable
5. The supervisory message is communicated via the NIC and RS-232 ports, as
applicable
6. Point- or group-specific and general-supervisory outputs activate, including
previously-silenced outputs.
Refer to Paragraph 3-2.5.6.1 for what to do when a remote supervisory message is
received.
N:02 070 SUPERVISORY ON MONITOR MODULE
FIFTH-FLOOR GATE VALVE
Supervisory On
Indication
Device Type
Node Number
Device Address 070
Device-Specific
Custom Message
