P/N 06-236530-001 1-9 August 2013
Figure 1-8. Network Interface Card (shown mounted to PCB)
1-3.4 Intelligent Interface Module (IIM)
The Intelligent Interface Module (IIM), shown in Figure 1-9, provides a communications
link to a network up to 127 ORION-XT Detectors for centralized data exchange, alarm
reporting, detector configuration, and history-log downloading.
Refer to the ORION-XT Installation, Operation and Maintenance Manual (Part Number
77.100) for a complete description of the Intelligent Interface Module.
Figure 1-9. Intelligent Interface Module
1-3.5 Fiber Optic Converter Card
The Fiber Optic Converter Card (OCC), shown in Figure 1-10, converts electrical signals
from the Network Interface Card into light pulses for data transmission over 62.5/125
m duplex fiber optic media. The OCC permits distances of up to 1 mile (5,280 ft.)
between networked ARIESs.
Combo 2
TB6TB7
Combo 1
TB2
Aux 24 VDC
TB11
Release 2
TB12
Release 1
Batt Out
TB3
TroubleRelay 3
Relay 1
Relay 2
1234 1234
1234
1 2 34 1 2 34
120
240
TB13
AC IN
NL
PSU
J12
+
+
--
CNCNO
CNCNO
CNCNOCNCNO
1234
TB5
NAC 1
TB14
1234
NAC 2
RS-232 A
J8
J3
TB15
USB B
RS 485SLC
TB1
4321 4321
Style 4
S2
J10
Network Interface Card
B2NA2B1NA1 B2IA2 B1IA1
TB1TB3TB2TB4
K1K3K2K4
J1
DS4 DS2 DS3 DS1
N2 N1 I2 I1
U11
GND
TP1
+5
TP2
I1
TP3
N1
TP4
N2
TP5
I2
TP6
RS-232 B
J6
CAT. NO. 89-100083-001
MODEL: IIM-2000
KIDDE-FENWAL, INC.
400 MAIN STREET,ASHLAND, MA 01721
TEL: (508) 881-2000 FAX: (508) 881-8920
R
ASHLAND, MA. 01721
KIDDE-FENWAL, INC.
IIM-2000
ASSY N0. 06-129728-001
PC CCM
TEL
-1
Module
Side View
Front View with Door Open
Latch
Ground
Lug
8"
5-1/2"
8"
2-9/32"
9/32" Diameter
9/32" Diameter
½" & ¾"
Knockout (2)
1-1/4"
1-1/16"
To Next Page
