Kidde ARIES

P/N 06-236530-001 3-115 August 2013
Figure 3-30. Typical Multiple Level-2 Event-Type Display
You may manually scroll the display among the active Level-2 events and
completed Level-1 events by using the <SCROLL> Key.
3-2.5.8.6 What to Do When Level-2 Messages are Displayed
Press the <SCROLL> Key to display the information for the highest-priority
and subsequent events. The display will show 1st event or "More than 64
Alarms" when all of current Level-2 and completed Level-1 events have
been manually displayed. The upper line of the display will revert to
showing the highest-priority event approximately 5 seconds after the last
press of the <SCROLL> Key. You may then manually scroll the display
among the active Level-2 and completed Level-1 events.
The appearance of the display when manually scrolling through the active
Level-2 events is shown in Figure 3-31.
Figure 3-31. Typical Display When Manually Scrolling Through Level-2 Events
010 ALARM ON PHOTOELECTRIC
DIS 00 CNTDN 00 ABT 01 ALM 02 PAS 00
Alarm Indication
Device Type Reporting Alarm
Device Address 010
No. of Alarms
No. of Activated Abort Stations
No. of Countdowns to Release in Progress
No. of Extinguishing-System Releases
No. of PAS Countdowns
in Progress
010 ALARM ON MANUAL STATION
COMPUTER ROOM
Alarm Indication
Device Type Reporting Alarm
Device Address 010
Device-Specific
Custom Message
