Listed and Approved Releasing Devices
P/N 06-236530-001 C-1 August 2013
APPENDIX C
LISTED AND APPROVED RELEASING DEVICES
C-1 RELEASING CIRCUIT ELECTRICAL CHARACTERISTICS
The following electrical characteristics apply to the dedicated releasing circuits, Release 1 and
Release 2.
C-2 COMBINATION CIRCUIT ELECTRICAL CHARACTERISTICS FOR RELEASING
The following electrical characteristics apply to the combination circuits, Combo 1 and Combo 2.
Table C-1. Release 1 and 2 Circuit Electrical Characteristics
Characteristic Solenoids Actuator
Maximum Devices. 2 1
Minimum Peak Firing Current 2.8 A / 30 ms 1.5 A / 10 ms
Maximum Steady Firing Current 2.4 A ---
Max. Open-Circuit Term. Voltage 28.0 28.0
Min. Open-Circuit Term. Voltage 20.0 20.0
Maximum Supervision Current 5 ma 5 ma
Dummy Load 10 k Ohms ---
Table C-2. Combo 1 and 2 Circuit Electrical Characteristics
Characteristic Solenoids Actuator
Maximum Devices 1 Do Not Use
Minimum Peak Firing Current 2.8 A / 30 ms ---
Maximum Steady Firing Current 2.4 A ---
Max. Open-Circuit Term. Voltage 28.0 ---
Min. Open-Circuit Term. Voltage 20.0 ---
Maximum Supervision Current 5 ma ---
Dummy Load 10 k Ohms ---
