August 2013 3-140 P/N 06-236530-001
Confirm EOC programming for Nodes 1 and 2. Add successive network
nodes one at a time as outlined in the procedure above and continue to
confirm proper networked operations. Use Node 1 as the point for adding
more control units to the network. Repeat this procedure until all the nodes
have been successfully added. Use a consecutive range of network node
addresses to simplify the process of bringing the network on line. Be sure
that each node being added shows “System Status Normal” before you add
it to the network.
Test the entire network for proper operation in accordance with the job
specifications and/or local fire codes. Verify proper operation for each
initiating device and output circuit.
3-3.21.1.4 Network Maintenance
A control unit must be isolated from the network before any maintenance
is performed. The other network control units will ignore all alarm,
supervisory, and trouble reports from the isolated control unit, and they
will report it as a network supervisory condition subject to the operating
rules discussed in Paragraph 3-3.8.
Any networked control unit can be isolated by a control unit designated as
Group 0, or by
Another control unit in the same group as the control unit to be
isolated
Any control unit in a network configured for global operation
The control unit itself
Use the following procedure to isolate a networked control unit:
1. Press the 0 Key on the keypad of the control unit being used to do
the isolation. The display will show this message:
Figure 3-79. Password Prompt
2. Enter the Level-2 Password and then press the <Enter> Key. The
network-node prompt will appear as follows:
Figure 3-80. Network Node Prompt
3. Select the local node by pressing the <Enter> Key, or enter a remote
node number then press the <Enter> Key. The top-level menu
selections will be displayed.
Figure 3-81. Top-Level Menu Selections
4. Press the 3 Key to select the Set sub-menu
Figure 3-82. Set Sub-Menu
PLEASE ENTER PASSWORD
****
PRESS ENTER TO SELECT THE LOCAL NODE
OR ENTER NETWORK NODE NO. (1 - 32)*
1: ISOLATE 2: LIST
3: SET 4: TEST
1: TIME/DATE 2: PRINTER CONTROL
3: SLC DEVICES SCROLL FOR MORE
