P/N 06-236530-001 3-139 August 2013
3. Select the local node by pressing the <Enter> Key. The top-level
menu selections will be displayed.
Figure 3-74. Top-Level Menu Selections
4. Press the 3 Key to select the Set menu and the following options will
appear:
Figure 3-75. Set Menu Selections
5. Press the <SCROLL> Key to display additional SET-Menu options.
Then press the 6 Key to select NETWORK
Figure 3-76. Set Menu Options
6. Press the <Scroll> Key and then the 4 Key to select ADD/REMOVE
NODES
Figure 3-77. Add/Remove Nodes
7. The display will indicate the following; press backspace to exit from
the menus.
Figure 3-78. Prompt to Add/Remove Network Nodes
8. Press the <Backspace> Key multiple times as required to exit the
Menu mode of operation. Nodes 1 and 2 will now begin
communications with each other.
1: ISOLATE 2: LIST
3: SET 4: TEST
1: TIME/DATE 2: PRINTER CONTROL
3: SLC DEVICES SCROLL FOR MORE
4: PROGRAMMING 5: GLOBALS
6: NETWORK SCROLL FOR MORE
7: CLEAR EVENTS 8:CLEAR TESTS
9: RESYNC NETWORK [<-] to return
NETWORK EVENT RESYNCHRONIZATION
IN PROGRESS...
