- 80 -
FUNCTION SETTINGS
SELF CHECK
The following messages appear on the display.
This function checks the battery voltage, the internal voltage, the hoist up and down or the
conditions of the stepping motor in the Transducer unit.
NO PROBLEM:
appears when the system has no problem.
MB (Main Board): ABNORMAL POWER SUPPLY VOLTAGE:
appears when the abnormal voltage detection of the battery is suspected.
HB (Hull Board): NO RESPONSE:
appears when the disconnection of the wiring between Hull Unit and the communication line
is suspected.
TRANSDUCER UNIT: BLOWN FUSE:
appears when the blown fuse in the hoist is suspected.
TRANSDUCER UNIT: UP (DOWN) LIMIT NOT DETECTED:
appears when the abnormal upper (down) limit switch is suspected.
TRAIN MOTOR: DISCONNECTION
appears when the abnormal train motor is suspected.
TILT MOTOR: DISCONNECTION
appears when the abnormal tilt motor is suspected.
TRAIN MOTOR: ABNORMAL DETECTION OF ORIGIN
appears when the abnormal train motor or the abnormal detection of training position inside
the Transducer unit is suspected.
TRAIN MOTOR: STEP OUT
appears when the abnormal train motor or the abnormal detection of training position inside
the Transducer unit is suspected.
NOTE!
Both TRAIN MOTOR: ABNORMAL DETECTION OF ORIGIN and TRAIN MOTOR: STEP OUT
appear when the Hall IC board in the Transducer unit is abnormal.
TRAIN MOTOR: DISCONNECTION, TRAIN MOTOR: ABNORMAL DETECTION OF ORIGIN and
TRAIN MOTOR: STEP OUT appear all when the Transducer unit is total breakdown.
Use the Cursor Shift key ( or ) to select
“RETURN MARK” and press the Cursor
Selection key (O / +) to close this menu.
Select “SAVE REPORT” to store the report of Self
Check in the USB memory.
