KONE NanoSpace™
Owner’s Manual
123 (196) OM-01.03.086
(B) 2016-01-11
© 2014 KONE Corporation
All rights reserved.
11.7 Technical rescue
Rescue chart part 1 of 3
a) See section 11.7.1 Moving the elevator car using Recall Drive Feature (RDF) (Page 126.)
b) See section 11.7.4 Moving the elevator car using the manual brake releasing device.
(Page 140.)
c) See section Moving the elevator car with lifting equipment. (Page 135.)
e) See Technical rescue chart part 2 of 3. (Page 124.)
f) See Technical rescue chart part 3 of 3. (Page 125.)
Is there power
supply for the
elevator?
Is the car near
floor level?
(± 0.2 m)
TECHNICAL RESCUE
NO
YES
Move the car by using recall
drive
feature (RDF) at iMAP.
a)
YES
NO
Move the car using a car lifting tool.
(Min. 150 mm up)
Release the safety gear.
c)
Ask the passengers if the car lighting
or the car emergency light is on. Ask
them also to press the alarm button.
Is any lighting in the car
operative? Does the alarm
buzzer sound?
NO
NO
YES
NO
If the car cannot be moved, call the emergency services. They can assist
passengers out using special equipment considering the situation.
Open the bottom floor landing door and switch
on the shaft light.
Does the car
move?
Does the car
move?
Move the car to the nearest
door zone. Door zone LED
should illuminate.
START HERE
Does the car
move?
YES
NO
Switch off the main
switch (220).
Move the car with
mechanical brake.
b)
YES
Estimate the floor which is the closest to the
elevator car.
Close the landing door and ensure that it is
mechanically locked.
Reset the pit safety device at iMAP.
YES
Go to the landing nearest to the elevator car.
e)
EMERGENCY
RESCUE
1091036.wmf
Open the doors and help the passengers out.
NOTE! Tell passengers to pay attention when
stepping to the landing if the car sill and the
landing sill are not on the same level.
Close the landing door afterwards and ensure that
it is mechanically locked.
f)
