KONE NanoSpace™
Owner’s Manual
65 (196) OM-01.03.086
(B) 2016-01-11
© 2014 KONE Corporation
All rights reserved.
Figure 13.Car door lock
8.7 Polyurethane buffers
8.7.1 Safety measures
Before starting work, note the following:
– All safety measures for normal elevator maintenance must be implemented and local
safety re
gulations must be followed.
Centre opening
Side opening
Low duty (R1) doors
Mid duty (R2) doors
Z
Y
X
Z
X
Y
Z
X X
Z
A
B
