10.6 Final limit switch tests
The following sections describe the final limit switch tests.
10.6.1 Testing the upper limit switch
Step Action Illustration/Note
1 Enable the door opening. LCEUI switch 263.
2 Make a car call to the bottom floor from
the maintenance acce
ss panel.
3 Let the doors open and switch on the
Recall Drive Fe
ature (RDF).
POS 270.
4 Close and lock the maintenance access
panel.
5 Load
test weights to the car for at least
60%
of the maximum rated load.
6 Go to the maintenance access panel.
7 Disable the door opening. LCEUI switch 263.
8 Switch off the Recall Drive Feature
(RDF).
POS 270.
9 Make a car call to the topmost floor from
the maintenance acce
ss panel.
10 Switch on the Recall Drive Feature
(RDF).
POS 270.
11 Drive upwards on RDF until the elevator
car hit
s the buffers.
12 Switch off the Recall Drive Feature
(RDF).
POS 270.
