8.2.5 Performing one-sided brake test
For more information on performing the one-sided brake test, see section 10
Periodical
inspections according to EN 81-1 Annex E.
8.3 Overspeed governor OL35
Figure 10.OL35 components
The following table describes the maintenance procedures for the OL35 components.
Table 13: Maintenance procedures
1 Flyweight 6 Trip wheel
2 Spring 7 Contact plate
3 Eccentric wheel 8 Test groove
4 Flyweight catch 9 Groove for normal use
5 Overspeed contact
Maintenance procedure Checking interval
Cleaning Once a year or when needed
Check the condition of the flyweights and the springs. Once a year
Check the operation of the overspeed contact. Once a year
Check the operation of the tension weight contact. Once a year
Check the wear of the rope groove. Once a year
5
3
1
7
6
5
4
3
2
1
1
008
747.wmf
8
9
