KONE NanoSpace™
Owner’s Manual
33 (196) OM-01.03.086
(B) 2016-01-11
© 2014 KONE Corporation
All rights reserved.
To reduce the risk of the entrance being obstructed when the elevator is required to operate in
firefighting service, the use of the elevator for moving refuse or goods must be restricted.
The installer of the elevator must provide instructions to the owner, including details according
to the table below. In practice, many of the preconditions will have been agreed with the
owner before signing the elevator delivery contract.
NOTE! In case of fire, a correctly operating firefighter elevator enables firefighters to reach
people requiring help as quickly as possible.
The owner of the elevator is recommended to ensure that the operation of the firefighter
elev
ator is verified regularly according to local regulations and standards. KONE
recommends to verify the operation once a year.
The following table describes the relevant EN 81-72 cla
uses for firefighter elevators.
Table 8: EN 81-72 clauses
EN 81-72
clause
In
formation
5.1 Environment/Building requirements. In practice this me
ans the following main
items:
– Principle and layouts of fire protected lobbies
– Principle and border temperatures during emergency
– Common shaft requirements in the case of group elevators
– Electric and electronic component protection in the fire protected lobby
– Protected cabling and separated power supply
with backup power supply
for the firefighting elevator
5.2 Fundamental firefighters lift requirements, for example, size of car and normal
use. Additionally
, for example, the following items:
– Serving every floor in the building, as we
ll as "dummy" and restricted
access floors (local variation exists which floors are served)
– Protection against water with a proper sewage system in the shaft pit
5.4 Rescue of trapped firefighters in the lift car, for example, external rescue and
self rescue
procedures. In practice this means the following main items:
– Trap door on the elevator car roof
– Ladders located in the trap door/ceiling, depending on the elevator type
– Ladders on the elevator shaft wall
5.8 Control systems, for example, description of functions. In pra
ctice this means
the following main items:
– Protection and isolation of electrical control system componen
ts within
normal and firefighting elevator. Malfunction in regular elevator does not
affect the firefighting elevator in the same group
– Priority call when the elevator is activated in fire service mode
