8.9.3 Checking belt tension
Check visually the belt tensioning device.
–
The gas spring should have no leaks or other visual damage.
– The gas spring piston should be in correct position (*).
A. No need for adjustment
B. Needs adjustm
ent
Replace the gas spring or shorten the tensioning rope, if needed.
A
B
1089059.wmf
