46
KMHA 500-000099
Revision D
KDR
TM
AU-DDR Advanced U-Arm System with
Dynamic Digital Radiography (KDR AU DDR)
14.3 Ultra Screen Overview: Sidebars
Figure 14.3.1
Ultra Screen Overview: Sidebars
14.4 Ultra Screen Overview: Lower Icons
NEW: this button starts the
“Add a New Patient Exam” process by opening a
new worklist entry for a new patient exam.
MORE: after selecting a
patient exam from the Completed tab, this button
launches the more options menu to allow you to
either burn the study to a CD/DVD, save the study
to external HDD, or print the study to a DICOM
printer (completed tab only.)
EMERGENCY: this button
allows you to complete a patient exam without any
patient information entered yet. Generic info will
populate into the elds. These elds will need to
be lled in with correct patient information before
sending the completed emergency exam to a PACS
server.
ACQUIRE: launches the UAI
Acquire screen and populates the appropriate
acquire elds with the selected exam information.
QUERY: this button per-
forms a MWL Query for any congured modality
worklist provider and populates the Ultra Worklist
screen with any resulting patient exams (worklist
tab only.)
IV. SOFTWARE
