III. USER INTERFACES
Figure 13.6.3
Bucky
NOTE: Illustrations of functions assume the user is directly facing the front of the stand.
13.7 Positioning
The positioner can be moved by three different methods: the 12 buttons on the face of the positioner control panel (see
Figure 13.7.1), the 12-button control panel on the Bucky handle (see Figure 13.7.2) or the 16-button remote control (see
Figure 13.7.3).
Linear Movements
The tube head and detector arm can be moved up or down.
Rotating Movements
The u-arm and detector arm (or swivel arm) can be rotated clockwise or counterclockwise.
