Konica Minolta KDR AU DDR User Manual

79
KMHA 500-000099
Revision D
KDR
TM
AU-DDR Advanced U-Arm System with
Dynamic Digital Radiography (KDR AU DDR)
19.2 Manually Stitching a Leg Length Study
Manual stitching can be performed when needed to complete a stitching study, if for example, you cancelled out of the
auto stitching procedure, or your positioner stand does not offer a feature to move automatically to a position based on
the view you select in Ultra.
1. From the Acquire screen, left click on the Ankles leg length view.
2. Right click on the Stitching icon located on the far right side of the Ultra toolbar.
3. Left click on the Knees leg length view.
4. Right click on the Stitching icon.
IV. SOFTWARE
