82
KMHA 500-000099
Revision D
KDR
TM
AU-DDR Advanced U-Arm System with
Dynamic Digital Radiography (KDR AU DDR)
NOTE: The rst position should always start at the top of the patient and move down towards the patient’s feet.
Also, make sure your collimation light is open completely from top to bottom. Position the stand at least a st’s
width away from the detector.
4. The software will now indicate that you are ready to take an exposure.
5. Your rst image will appear. The blue light on the stand will indicate when to again press and hold the MOVE
button on the remote.
IV. SOFTWARE
