magicolor 8650 2-13
Before using the machine
2
Mailbin kit MT-502
8
7
6
5
4
9
No. Part name Description
4 Bin 4 Collects printed pages.
5 Bin 3 Collects printed pages.
6 Bin 2 Collects printed pages.
7 Bin 1 Collects printed pages.
8 Guide lever FN7 Moved when clearing paper misfeeds within the mailbin kit.
9 Misfeed-clearing door Opened when clearing paper misfeeds within the mailbin kit.
