2.1.5 Saddle stitcher SD-505/Mailbin kit MT-502
Saddle stitcher SD-505
23
1
No. Part name Description
1 Output tray Collects printed pages.
2 Misfeed-clearing door Opened when clearing paper misfeeds within the saddle stitcher.
3 Misfeed-clearing door re-
lease lever
Used to open the Misfeed-clearing door.
