Konica Minolta Network Printer - FS-110;210 Finisher (Option)

Media Information 4-5
Media Information
FS-110/210 Finisher (Option)
FS-110/210 In-Bin Stapler Finisher accepts LEDGER (11"x17"), LEGAL (8.5"x14") and
LETTER/R (8.5"x11"/R) standard/wide paper sizes (5.5"x8.5"R/W in Non-sort, Sort or
Group mode).
FS-110/210 Finisher Primary (Main) Tray
FS-110/210 Finisher (capacities at 20lb, unless otherwise indicated)
Non-sort/Sort/Group mode:
500 sheets 5.5"x8.5"/5.5"x8.5"W, 5.5"x8.5"R/5.5"x8.5"WR (A5/A5W, A5R/A5WR)
3,000 sheets 8.5"x11"/8.5"x11"W, 8.5"x11"R/8.5"x11"WR (A4/A4W, A4R/A4WR,
B5/B5W, B5R/B5WR) (using FS-110 Finisher)
2,500 sheets 8.5"x11"/8.5"x11"W, 8.5"x11"R/8.5"x11"WR (A4/A4W, A4R/A4WR,
B5/B5W, B5R/B5WR) (using FS-210 Finisher)
1,500 sheets 11"x17"/11"x17"W, 8.5"x14" (A3/A3W, B4/B4W)
Staple-sort mode:
1,000 sheets* 11"x17"/11"x17"W, 8.5"x14", 8.5"x11"/8.5"x11"W, 8.5"x11"R/
8.5"x11"WR
*Variable according to the number of pages to be stapled. See the table below.
Paper Capacity for Staple-sort mode of FS-110/210 Finisher
(for the same size paper only)
11"x17"/11"x17"W (A3/A3W)
8.5"x14 " , 8.5”x11 " /8.5 " x11 " W,
8.5
" x11 " R/8.5 " x11 " WR (B4/B4R,
A4/A4W, A4R/A4WR, B5/B5W, A5/A5W
)
No. of prints 2 staples 1 staples 2 staples 1 staples
2~9 50 sets 50 sets 100 sets 100 sets
10~20 50 50 50 50
21~30 30 30 30 30
31~40 25 25 25 25
41~50 20 20 20 20
Your service representative can set the printer to stop printing when the number of
prints exceeds above capacity.
Contact your service representative for information.
