23 TECHNICAL DATA 195
23.7 Tires
Front tires Rear tires
120/70 R 17 M/C 58H TL
Continental Conti Attack SM
160/60 R 17 M/C 69H TL
Continental Conti Attack SM
Additional information is available in the Service section under:
http://www.ktm.com
23.8 Fork
Fork part number 14.18.8N.25
Fork WP Suspension 4860 ROTA SPLIT
Compression damping
Comfort 20 clicks
Standard 15 clicks
Sport 10 clicks
Full payload 10 clicks
Rebound damping
Comfort 20 clicks
Standard 15 clicks
Sport 10 clicks
Full payload 10 clicks
Spring length with preload spacer(s) 463 mm (18.23 in)
Spring rate
Medium (standard) 5.3 N/mm (30.3 lb/in)
Air chamber length 110
+20
30
mm (4.33
+0.79
1.18
in)
Fork length 895 mm (35.24 in)
Fork oil per fork leg 625 ml (21.13 fl. oz.) Fork oil (SAE 4) (48601166S1) ( p. 225)
23.9 Shock absorber
Shock absorber part number 15.18.7L.12
Shock absorber WP Suspension 4618 with ProLever deflector
Compression damping, high-speed
Comfort 2 turns
Standard 1.5 turns
Sport 1 turn
Full payload 1 turn
Compression damping, low-speed
Comfort 25 clicks
Standard 20 clicks
Sport 15 clicks
Full load capacity 15 clicks
Rebound damping
Comfort 20 clicks
Standard 15 clicks
Sport 10 clicks
Full payload 10 clicks
Spring preload 20 mm (0.79 in)
Spring rate
Medium (standard) 80 N/mm (457 lb/in)
Hard 85 N/mm (485 lb/in)
Spring length 220 mm (8.66 in)
Gas pressure 10 bar (145 psi)
