KTM 2014 690 SMC R EU User Manual

8 SHOCK ABSORBER, SWINGARM 38
G00825-10
–
Mount screw

but do not tighten yet.
–
Mount and tighten screw

.
Guideline
Screw, bottom shock
absorber
M10 45 Nm
(33.2 lbf ft)
Loctite
®
243™
–
Tighten screw

.
Guideline
Screw, top shock absorber M10 45 Nm
(33.2 lbf ft)
Loctite
®
243™
G00818-12
–
Mount and tighten screws

.
Guideline
Screw, fuel tank, bottom M8 25 Nm
(18.4 lbf ft)
Loctite
®
243™
G00742-15
– Lift the rear fairing.
–
Mount and tighten screws

.
Guideline
Screw, main silencer holder on fuel
tank
M8 25 Nm
(18.4 lbf ft)
G00816-14
–
Mount and tighten screws

.
Guideline
Screw, side cover M6 5 Nm (3.7 lbf ft)
G00821-11
–
Position grab handle

.
–
Mount and tighten screws

.
Guideline
Screw, handrail M8 20 Nm
(14.8 lbf ft)
Finishing work
– Mount the side cover. ( p. 62)
