MX’er SYSTEM
Move the spring up and down.
Inspect the swing arm.
Replace if crack, bend or damage.
Roll the axle on a flat surface to inspect the
pivot shaft.
Replace if bends.
Inspect the thrust cover, chain guard, collar and
bush.
Replace if wear or damage.
INSTALLATION
Reverse the “REMOVAL” procedure.
Apply grease onto the collar, bush, pivot shaft
and thrust cover.
Install the swing arm and tightening the nut.
Torque: 6.0 8.0kgf-m
