13. REAR WHEEL/SWING ARM/
HYDRAULIC BRAKE
13
-
16
MX’er SYSTEM
Install the shock absorber and tightening the
bolt.
Torque: 3.5 4.5kgf-m
Install the shaft, washer and cotter pin.
Install the rear hub and rear wheels.
Refer to the “REAR WHEEL
INSTALLATION” section.
Adjust the drive chain slack.
Refer to the “DRIVE CHAIN SLACK
ADJUSTMENT” section in the CHAPTER 3.
Approximately: 30 mm
HYDRAULIC BRAKE
BRAKE FLUID CHANGE/AIR
BLEED
Place the motorcycle on its main stand on level
ground and set the handlebar upright.
Remove the two screws attaching the brake
fluid reservoir cap.
Use shop towels to cover plastic parts and
coated surfaces to avoid damage caused by
splash of brake fluid.
*
Pivot Shaft
Always use a new cotter pin.
*
