Kyocera FS FS-1920 User Manual

Waste Toner Box Replacement
3-6
Waste Toner Box Replacement
Replacing the Waste Toner Box
When replacing the toner container, the used waste toner box in the
printer should also be replaced with the new one from the new toner kit.
1
Open the left cover on the left side of the printer.
2
While holding the waste toner box, press the lock lever and then
gently remove the waste toner box.
Remove the waste toner box as gently as possible so as not to scatter
the toner inside. Do not let the opening of the waste toner box face
downward.
Note
Left Cover
Old Waste
Toner Box
Lock Lever
Note

Kyocera FS FS-1920 Specifications

General

Print Technology	Laser
Print Speed	19 ppm
Resolution	600 x 600 dpi
Max Paper Size	A4
Connectivity	USB 2.0
Memory	32 MB
Duplex Printing	Manual
