Installing Option Units
A-28
Microdrive (Hard Disk)
Insert the Microdrive into its slot on the main circuit board of the printer. If
a Microdrive is installed in the printer, received data can be rasterized and
stored on this Microdrive. This enables high-speed printing of multiple
copies using an electric sort function. Also, you can use the e-MPS
functions. For details, see e-MPS on page 1-56.
For details of available Microdrives, see your dealer.
1
Turn off the printer and disconnect the power cord and printer cable.
2
Remove the two screws from the rear panel.
3
Pull the main circuit board all the way out of the printer.
Rear Panel
Screws
Main Circuit
Board
To Next Page
