6600 Product Manual
Operator Manual
1
Chapter 1 Overview
1.1 Performance characteristics
Digital X-ray Radiography System is an X-ray imaging device developed and produced
by Shenzhen Lanmage Medical Technology Co., Ltd., mainly consisting of high voltage
generator, high voltage cable, X-ray tube assembly, collimator, flat panel detector,
photographic bed and image processing. Available for medical education, scientific
research, medical units for head, abdomen, chest and limbs, bones of chest position and
the table position etc. radiographs for the diagnosis.
The main performance characteristics of the system are as follows:
FIG. 1-1 Arrangement of main parts of machine
2 X-ray tube assembly 3 Collimator 4 Column
5 Radiography Table 6 Detector Bucky 7 C arm 8 Handle
9 Generator 10 Workstation
The main performance characteristics of the system are as follows:
◼ Constant pressure operation;
◼ The operation process is convenient and efficient
◼ Under the bed, 1.0m and 1.8m chest radiograph position when the ball tube and
detector are in position with one key;
◼ It can realize the photographic examination of human limbs, head, chest, spine
NOTE: The equipment provides different configurations and property
parameters to satisfy client’s demands.
