LeeBoy 8520C - Paver Performance and System Specifications; Performance, Lubricant, and Capacity Specifications; Relief Pressure Specifications

Table 2-3. Performance Specications
ITEM SPECIFICATION
Engine Low Idle Speed 1300 RPM
Engine Maximum Speed 2200 RPM
Travel Speed 0 - 3.4 mph; 0 - 300 feet per minute (FPM)
Paving Speed 0 - 1.98 mph; 0 - 174 FPM
Recommended Paving RPMs 1900 RPM / 2100 RPM with generator on.
Maximum Paving Depth 6 in
Gradeability 20%
Table 2-4. Lubricant Specications
ITEM SPECIFICATION
Engine Oil 15W-40 API CJ-4
Hydraulic Oil All-Weather 32
Torque Hub 50 WT Gear Oil or Equivalent
Anti-Seize Lubricant Recommend using Zep Groovy (a can is shipped with
your paver).
Grease Shell Avania EP Grease or Equivalent
Chain Lube Chain Lube Agent
Table 2-5. Machine System Capacity Specications
ITEM SPECIFICATION
Engine Lubrication Oil (Rell Capacity) 17 qt
Hydraulic Oil Tank 25 gal
DEF Tank 5 gal
Torque Hubs 32 oz each
Diesel Fuel Tank 32 gal
Spray Down Tank 7 gal
Coolant 3.25 gal. (Glycol-Based, Extended Life)
Table 2-6. Relief Pressure Specications
ITEM SPECIFICATION
Pump (Propulsion) 3625 psi
Cylinder Pump 2400 psi
Conveyor Pump 3400 psi
Auger Pump 3400 psi
Track Tensioning Relief 1200 psi
Charge Pressure 350 - 400 psi
Track Tension Pressure 175 psi
Park Brake Release 290 psi
22
LeeBoy 8520C Conveyor Paver
2-5
Information and Specications
