LeeBoy 8520C - Paver Component Specifications; Hopper, Screed, and Electrical Specifications; Generator and Track Specifications

Table 2-7. Hopper Specications
ITEM SPECIFICATION
Material Capacity 9 Tons
Height 31.75 in
Wings
Heavy duty; 1/2 in (12.7 mm) with large radius corners
and rear hopper wing wipers.
Table 2-8. 815 HD (Heavy Duty) Screed Specications
ITEM SPECIFICATION
Screed Weight 3450 lbs
Electric Heat Elements
Two (2) 3000-watt S-Curve elements on main screed.
One (1) 1500-watt element on each screed extension.
Main Screed Width 8 ft
Screed Extension Width (2, Hydraulically-Operated) 3 ft 8 in
Wear Plates
Main Screed Depth: 1.47 ft [.375 in Thick]
Extension Depth: 7.38 in [.375 in Thick]
Bullnose Radius
Main Screed: 2 in
Screed Extension: 1.5 in
Vibration
Two (2) vibration motors producing 4100 vpm
Slope @ 15 ft (4.6 m) 3.5 in
Crown/Valley @ 10 ft (3 m)
Positive Crown: 2.5 in
Negative Crown: 1.50 in
Table 2-9. Electrical Specications
ITEM SPECIFICATION
Battery (1) 12 Vdc Maintenance Free, 12 Volts, Negative Ground
Cold Cranking Amps (CCA) 950 CCA
Alternator 100 Amp
Starter Voltage and Type 12-Volt, Negative-Ground
Circuit Protection Fuses, Breakers and Disconnect
Table 2-10. Generator Specications
ITEM SPECIFICATION
Power 14,400 watt
Voltage 240 Volts
Frequency 57 - 63 Hz
Table 2-11. Track Specications
ITEM SPECIFICATION
Poly/Steel (2-Speed, 36 Pads)
Length: 5 ft 6 in
Width: 1.2 ft
Rubber (2-Speed)
Length: 5 ft 6.75 in
Width: 1.4 ft
LeeBoy 8520C Conveyor Paver
2-6
Information and Specications
