LeeBoy 8520C Conveyor Paver 4-19
Operation
DPF LevelsDPF Levels
There are ve DPF levels. DPF warning messages will
appear according to the soot level present. (Figures
4-36 to 4-42)
It is important to perform a parked
regeneration BEFORE the DPF level reaches Level
4. If the regeneration process is not performed and
the soot level reaches Level 4, non-warranty factory
assistance from the engine manufacturer is required.
Regen Level 1: The DPF is loaded with soot and needs
to be regenerated. (Figure 4-36) This message alerts
the operator of the system’s need for regeneration.
Figure 4-36. Regen Level 1 Warning
NOTE: If the operator has not inhibited regenera-
tion and there are no engine faults, but auto-
matic regeneration is not occurring, increase
engine RPMs and/or load to allow the DPF to
automatically regenerate. This only applies at
DPF Level 1 and 2.
Regen Level 2: The rst Level 2 screen is the warning.
The DPF is loaded with soot and needs to be regener-
ated. (Figure 4-37)
Figure 4-37. Regen Level 2 Warning
Scroll down using the DOWN (V) button to read the
remainder of the message for regeneration instructions.
(Figure 4-38)
Figure 4-38. Secondary Regen Level 2 Message
