Select the operating mode
The device may operate in two different modes:
- Bistable (to operate the rolling shutter press and immediately release the UP or
DOWN keys).
- Monostable (to operate the rolling shutter press and hold down the UP or DOWN
keys).
The device is supplied configured in bistable mode. It will be possible to change
the operating mode at any time by pressing and holding down for more than
4 seconds both the UP and DOWN pushbuttons at the same time.
Configuration
Adjustment of the blade position:
Press the UP and DOWN pushbuttons for more than 1 second.
Opening and closing the rolling shutter:
Press and release the UP and DOWN pushbuttons.
Use of the device in bistable mode
> 4 sec.
> 1 sec.
Shutter control
Shutter control
Shutter control
Shutter control
> 1 sec.
Individual roller blind controller RF ZigBee for mounting in
technical compartment
