Control/actuator
MQ00411-e-EN 19/06/2014
For the “ON/OFF with adjustment” function, “Timed ON” with parameter 2sec, 10min,
15min, “Blinking”, “Cyclic with custom point-to-point adjustment”, “ON/OFF with custom
point-to-point adjustment”, “Cyclic with custom adjustment” and “Custom cyclic dimmer
with no adjustment” use virtual configuration via MYHOME_Suite
5.1.1 ON/OFF Control and ADJUSTMENT (Point-to-Point only):
Virtual configuration (MYHOME_Suite) Physical configuration
Parameter / setting
ON/OFF and cyclic ADJUSTMENT.
ON/OFF when pressing briefly and adjustment when holding down.
M2=0
ON with top button, OFF with bottom button and DIMMER when held down M2=0/I
5. Mode of operation of the control by the right button
5.1 ON/OFF control
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Cyclic. M2=0
ON M2=ON
OFF M2=OFF
Button M2=PUL
Timed ON 0.5sec M2=8
30sec M2=7
1min M2=1
2min M2=2
3min M2=3
4min M2=4
5min M2=5
15min M2=6
Remove actuator “control”
button cover
Or
5.2 Automation
Virtual configuration (MYHOME_Suite) Physical configuration
Parameter / setting
Bistable control
M2=
Monostable control
M2=M
For bistable control + lath control use MYHOME_Suite virtual configuration
Remove actuator “control”
button cover
