0883 28 3578
Open Web Net/Zigbee Gateway
Interface for interaction with the functions of the ZigBee radio system using a Personal
Computer and an Open Web Net communication protocol.
The device must be connected to a USB port of the computer and features a radio
transmitter for sending/receiving data to and from ZigBee devices installed in the
electric system.
Description
Front view
Legend
1. USB connector
2. Data traffic indicator LED
3. NETWORK key
4. NETWORK LED
Power supply: From USB 2.0 socket
Operating temperature: 5 – 45 °C
Technology: Radio 2.4 GHz standard ZigBee®
Capacity: 150 m free field, 15 m in rooms with concrete walls
Technical data
Side view
MQ00493-b-EN 04/07/2013
