313
M
OUT 3
OUT 2
OUT 1
N
L1
OUT 3
OUT 2
OUT 1
L
N
230 Vac
F430R3V10
+
–
+
–
7
8
5
6
M
M
0 – 10 V
0 – 10 V
F430R3V10
24/09/2013MM00781-a-EN
Fan-coil actuator with 0-10 V valves
Wiring diagrams
Example of connection of a 4-tube fan-coil with 0-10 V valves.
