Actuator 16A with current sensor
MQ00361-d-EN 09/06/2014
The device can be configured in two ways:
- PHYSICAL CONFIGURATION, inserting the configurators in position.
- Configuration via MYHOME_Suite software package, downloadable from
www.homesystems-legrandgroup.com; this mode has the advantage of offering
many more options than the physical configuration.
For a list of the procedures and their meanings, please refer to the instructions in this
sheet and to the "Function Descriptions" help section in the
MYHOME_Suite software
package.
Configuration
1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL = 1-9
NOTE 1): Only for a point-point type control. With the OFF control the Master actuator deactivates;
the Slave actuator deactivates after the time set with the configurators has elapsed. In the Off
delayed mode, the master sends the Off command after a period of time set using the 1 - 4
configurator connected to M as shown in the table.
1.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator Master M=0
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave M=SLA
Pushbutton (ON monostable) ignores Room and General controls Master PUL
OFF Delay = 0
M=PUL
Master Actuator with OFF control delayed on the corresponding
Slave actuator.
1)
Master PUL
OFF Delay = 1 - 255
M=1 1 minute
M=2 2 minutes
M=3 3 minutes
M=4 4 minutes
To use the "Actuator as a slave with PUL function", "Load status upon central unit
enabling" and to select the type of load (Actuator, Lamp, Valve, Differential Reset, Fan,
Irrigation, Controlled Outlet, Lock) use MYHOME_Suite virtual configuration.
List of Functions
The device performs the following functions:
1. LIGHT SWITCH
2. LOAD CONTROL ACTUATOR
1. Lights actuator
The actuator performs all the operating modes that can be configured on the control
devices, with the exception of those requiring the use of two interlocked relays.
Moreover further operating modes with the configurator in position M of the same
actuator are listed in the table below.
In the A and PL positions it will be necessary to indicate the device addresses in order
for this to be reached as automation actuator. In order to display the instantaneous
and cumulative consumptions of the controlled load (saved inside the actuator), it will
be necessary to configure also P1 and P2. In this case P1 and P2 do not indicate the
cut-off priority, but the address to be entered in the software programs in order to make
it possible to display consumptions on the dedicated pages.
To configure the group address 0-255, use MYHOME_Suite virtual configuration.
