Actuator 16A with current sensor
MQ00361-d-EN 09/06/2014
LED signals according to the status of the actuator in automation mode:
Device status LED
Load OFF GREEN
Load ON ORANGE
2. Load control actuator
Power factor
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Power
factor
Typical loads
1)
Power factor % 0-100 % PF=0
0.92
(default)
vacuum cleaner, microwave,
TV
PF=1 1
oven, iron, electric stoves,
hair straightener, hot loads,
electron. transformers,
Toroid. transformers
PF=2
0.85 CFL lamps
PF=3
0.8
PF=4
0.75 Washing machines, dish-
washers, desktop PCs
PF=5
0.7
PF=6
0.65
PF=7
0.6 Other electronic devices
(home theater, DVD recorder,
notebook PC, etc.)
PF=8
0.55
PF=9
0.5
To use "Phase" (Single, 1, 2, 3), "Load Type" (Single Phase, Three Phase), "Load status
upon central unit enabling" (Previous state, Off) to select "AC or DC voltage", the
selection of the voltage to be measured (automatic or from 1 to 255V), "Upper threshold
for diagnosing the residual current" and "Power threshold on standby for energy
management actuators" use MYHOME_Suite virtual configuration.
NOTE 1:
The parameters listed in the table are only indicative.
2.1 Load control management mode:
In the P1 and P2 positions it will be necessary to indicate the priorities from 01 to 63, in PF
the power factor (see table), the A, PL and M positions must be configured equal to zero.
To use "Phase" (Single, 1, 2 and 3), "Type of load", "Load status upon central unit
enabling" and "AC or DC voltage" use MYHOME_Suite virtual configuration.
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Priority 1-63 P1,P2: 01-63
