F522
Actuator 16A with current sensor
MQ00361-d-EN 09/06/2014
2.2 Lights and load control management mode:
In positions P1 and P2 priority from 01 to 63 must be indicated (see table above), in A and
PL you need to indicate the address of the device, as specified on page 2.
LED signals according to the status of the actuator in lights control and load
control management mode:
Common LED notifications:
Device status LED
Device status LED
Enabled + ON ORANGE
Enabled + OFF GREEN
Enabled + ON with consumption less than
50 W
ORANGE flashing 900 ms ON/100 ms OFF on GREEN
Disabled RED
Forced + ON ORANGE flashing 1s/1s on GREEN
Forced + OFF ORANGE flashing 1s/1s
Installation error (230 Vac not detected) Flashing RED 100 ms/900 ms
Configuration error ORANGE flashing irregularly on GREEN
Not configured ORANGE flashing 128 ms/128 ms on GREEN
LED signals according to the status of the actuator in load control management
mode:
Device status LED
Enabled ORANGE
Enabled with consumption less than 50 W ORANGE flashing 900 ms ON/100 ms OFF on GREEN
Forced ORANGE flashing 1s/1s on GREEN
Disabled RED
