471
Power
F551
Connection of the switches in series, to increase the number of LAN lines available on the output
Patch module
F550C6
Switch
F551
Power supply
F522
Patch cords
L4665L20 L4665L40
LAN input
Wiring diagram
LAN input
5 port switch
MQ00322-b-EN 21/05/2014
