NOTE 1): In the Master and Master PUL mode you can set an OFF delay of 0-255 seconds (via
MYHOME_Suite) and of 1-4 minutes using the physical configuration. Only for a point-point type
control. With the OFF control the Master actuator deactivates; the Slave actuator deactivates after
the time set with the configurators has elapsed.
Typical function for use in bathrooms without windows where the ON control activates the light
(Master actuator) and the ventilation fan (Slave actuator) at the same time. The OFF control
switches the light off immediately and leaves the fan working for the time set with configurator 1
to 4 in M of the Master actuator as indicated in the table.
When installed in a Lighting Management system, the device can be configured in the
following ways:
- Plug & Go: automatic procedure for pairing devices connected to the inputs and outputs.
The procedure is activated on powering the device. It is only available for Room Control
-
lers or, in the case of other devices, paired with the Room Controllers.
- Push & Learn: procedure for pairing different connected devices or changing the assign
-
ments defined automatically in the Plug & Go procedure. For more details, please refer
to the specific document.
- Software Configuration: using the Virtual Configurator software; for more details, please
refer to the specific manual.
1.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator Master M=0
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave M=SLA
Pushbutton (ON monostable) ignores Room and General controls Master PUL M=PUL
OFF delay: Master actuator with OFF control delayed on the
corresponding Slave actuator.
1)
0 - 255 M=1 1 minute
M=2 2 minutes
M=3 3 minutes
M=4 4 minutes
1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL=1-9
Group Group 1 - Group 10: 0-255 G=0-9
Configuration
To use the "Actuator as a slave with PUL function" and to select the type of load (Actuator,
Lamp, Solenoid Valve, Differential Reset, Fan, Irrigation, Controlled Outlet, Lock) and for
the "Local button mode" use MYHOME_Suite virtual configuration.
Basic Actuator
