65
002602
BMSW1003
SCS actuator 4x16A
MQ00313-e-EN 09/06/2014
2.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL1, PL2, PL3, PL4 = 1-9
NOTE 1): In the Master and Master PUL mode you can set an OFF delay of 0-255 seconds (via
MYHOME_Suite) and of 1-4 minutes using the physical configuration. With the OFF control the
Master actuator deactivates; the Slave actuator deactivates after the time set with the configu-
rators has elapsed. Typical function for use in bathrooms without windows where the ON control
activates the light (Master actuator) and the ventilation fan (Slave actuator) at the same time. The
OFF control switches the light off immediately and leaves the fan working for the time set with
configurator 0 to 4 in M of the Master actuator as indicated in the table.
This mode is only operative if PL1≠PL2≠PL3≠PL42).
2.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator Master M=0
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave M=SLA
Pushbutton (ON monostable) ignores Room and General controls Master PUL M=PUL
OFF delay: Master actuator with OFF control delayed on the
corresponding Slave actuator.
1)
0 - 255 M=1 1 minute
M=2 2 minutes
M=3 3 minutes
M=4 4 minutes
To use the "Actuator as a slave with PUL function", to select the "Type of load" (Actuator,
Lamp, Valve, Differential Reset, Fan, Irrigation, Controlled Outlet, Lock) and to select the
"Local button mode" (Cyclical, ON/OFF, ON-OFF, Pushbutton, Timed ON) use MYHOME_
Suite virtual configuration.
To configure the "Groups" use MYHOME_Suite virtual configuration
If the device is installed in a My Home system it can be configured in two ways:
- PHYSICAL CONFIGURATION, inserting the configurators in position.
-
Configuration via MYHOME_Suite software package, downloadable from
www.homesystems-legrandgroup.com; this mode has the advantage of offering many
more options than the physical configuration.
For a list of the procedures and their meanings, please refer to the instructions in this
sheet and to the "Function Descriptions" help section in the MYHOME_Suite software
package.
When installed in a Lighting Management system, the device can be configured in the
following ways:
- Push & Learn: procedure for pairing different connected devices or changing the assign
-
ments defined automatically in the Plug & Go procedure. For more details, please refer
to the specific document.
- Software Configuration: using the Virtual Configurator software; for more details, please
refer to the specific manual.
Configuration
1. Lighting Management System
2. My Home system
