Rolling shutter actuator
MQ00593-c-EN 09/06/2014
If the device is installed in a My Home system it can be configured in two ways:
- PHYSICAL CONFIGURATION, inserting the configurators in position.
-
Configuration via MYHOME_Suite software package, downloadable from
www.homesystems-legrandgroup.com; this mode has the advantage of offering many
more options than the physical configuration.
For a list of the procedures and their meanings, please refer to the instructions in this
sheet and to the "Function Descriptions" help section in the MYHOME_Suite software
package.
1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL=1-9
Group Group 1 - Group 10: 0-255 G=0-9
Configuration
1.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator
1)
Master M=0
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave M=SLA
Pushbutton (ON monostable) the actuator ignores Room and
General controls
Master PUL M=PUL
NOTE 1): Operation based on the mode configured in the control device. After acquiring the posi-
tions of the rolling shutter (open and closed), it will be possible to ensure 100 different positions.
1.2.1 Type of motor
Virtual configuration (MYHOME_Suite) Physical configuration
Type
Parameter / setting
Standard with automatic calibration Standard automatic Type=-
Standard with manual calibration Standard Type=1
Pulse Pulse Type=2
NOTE:
To adjust the "Stop pulse duration" and "Up or down pulse duration" use MYHOME_Suite
virtual configuration.
After inserting 2 in the Type socket and 9 in the Pre position of the device, when the
STOP pushbutton of the control is pressed while the shutter is still, the shutter will
move to the position of the 3rd limit switch.
1.3 Operating mode for pulse motors with a 3rd limit switch:
To use the "Actuator as a slave with PUL function" and to define the Preset positions, use
MYHOME_Suite virtual configuration.
To Next Page
