If the device is installed in a My Home system it can be configured in two ways:
- PHYSICAL CONFIGURATION, inserting the configurators in position.
-
Configuration via MYHOME_Suite software package, downloadable from
www.homesystems-legrandgroup.com; this mode has the advantage of offering many
more options than the physical configuration.
For a list of the procedures and their meanings, please refer to the instructions in this
sheet and to the "Function Descriptions" help section in the MYHOME_Suite software
package.
When installed in a Lighting Management system, the actuator can be configured in the
following ways:
- PLUG&GO
- PROJECT&DOWNLOAD
Configuration
1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL=1-9
1.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator Master M=0
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave M=SLA
Pushbutton (ON monostable) ignores Room and General controls Master PUL M=PUL
To use the "Actuator as a slave with PUL function" and to adjust the "OFF delay", the
"Type of load" (Actuator, Lamp, Valve, Differential Reset, Fan, Irrigation, Controlled
Outlet, Lock) and the "Local button mode" (Cyclical, ON/OFF, ON-OFF, Pushbutton,
Timed ON) use MYHOME_Suite virtual configuration.
1. Light switch
NOTE:
To configure the "Group" address use MYHOME_Suite virtual configuration
2.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL=1-9
2. Shutter automation control
NOTE:
To configure the "Group" address use MYHOME_Suite virtual configuration
4 relay actuator 2A
