F411/4
2.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator Master M=0
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave M=SLA
Pushbutton (ON monostable) ignores Room and General controls Master PUL M=PUL
Timed stop for shutter motor drives. The actuator switches
off after the set time has elapsed.
This mode is only operative if PL1=PL2=PL3=PL4 with relay
interlocking in pairs.
1-60 seconds,
2-10 minutes,
∞
PL1=PL2=PL3=PL4
M=0 20 seconds
M=1 15 seconds
M=2 25 seconds
M=3 60 seconds
To use the "Actuator as a slave with PUL function" and for the "Local button mode" (Cyclical, ON/
OFF, ON-OFF, Pushbutton, Timed ON) use MYHOME_Suite virtual configuration.
4 relay actuator 2A
MQ00276-e-EN 07/06/2014
3.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=0-9
Lighting point 0-15 PL=1-9
3. Rolling shutter automation control
NOTE:
To configure the "Groups" use MYHOME_Suite virtual configuration
3.2 Mode
Virtual configuration (MYHOME_Suite) Physical con-
figuration
Function Parameter / setting
Master Actuator Master M=0
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave M=SLA
Pushbutton (ON monostable) ignores Room and General controls Master PUL M=PUL
Timed stop for rolling shutter motor drive.
The actuator switches off after the set time has elapsed. This
mode is only operative if PL...=PL...+1 (same configurators),
therefore with the two relays interlocked.
1-60 seconds,
2-10 minutes,
∞
PL...=PL+1
M=0 1 minute
M=1 2 minutes
M=2 5 minutes
M=3 10 minutes
M=4 Until the motor's limit stop
M=5 20 seconds
M=6 10 seconds
M=7 5 seconds
M=8 15 seconds
M=9 30 seconds
