3Ethernetconnector
ConnectyourcomputertoaLANwiththeEthernetconnector.
Twoindicators,tothelowerleftandthelowerrightoftheconnector,showthestatusofthenetwork
connection.WhenyourcomputerconnectstoaLANandasessionwiththenetworkisavailable,thelower
leftindicatorissolidgreen.Whiledataisbeingtransmitted,thelowerrightindicatorblinksyellow.
DANGER
Toavoidtheriskofelectricalshock,donotconnectthetelephonecabletotheEthernetconnector.
YoucanonlyconnectanEthernetcabletothisconnector.
4eSATA/USBcomboconnector(left)
TheUniversalSerialBus(USB)connectorsareusedforconnectingUSBinterface-compatibledevices,such
asaprinterordigitalcamera.
Note:YourcomputeriscompatiblewithUSB1.1orUSB2.0.
YoucanalsoconnectanexternalSATAdevice,suchasanexternalharddiskdrive,tothisconnector.
Note:Toavoiddamagingtheconnector,becarefulwhenyouattachacablefromtheexternalSATAdevice
totheconnector.
5DisplayPortconnector
YourcomputermayhaveaDisplayPortconnector,thelatestdigitaldisplayinterfaceforconnectionto
variousexternaldevices.
TheDisplayPortconnectorsupportsadaptersthatcanplugintoDVIorVGAport.
654mm-wideExpressCardslot
Yourcomputerhasa54mm-wideExpressCardslot.
Fordetails,refertotheinstructionsin“Usingthemediacardreader”onpage57
.
7Comboaudiojack
Yourcomputerhasacomboaudiojack.Tolistentothesoundfromyourcomputer,connectaheadphoneor
aheadset,thathasa3.5mm4-poleplug,tothecomboaudiojack.
Thecomboaudiojackdoesnotsupportaconventionalmicrophone.Formoreinformationabouttheaudio
devicessupportedbythecomboaudiojackofyourcomputer,see“Usingaudiofeatures”onpage56.
Note:
Ifyouareusingaheadsetwithafunctionswitch,forexample,aheadsetforaniPhone
®
mobiledigital
device,donotpressthisswitchwhileusingtheheadset.Ifyoupressit,theheadsetmicrophonewill
bedisabled,andtheinternalmicrophonewillbeenabledinstead.
6UserGuide
