Leuze BPS 348i - BPS Without Heating

Technical data
Leuze electronic GmbH + Co. KG BPS 348i 112
Tab.13.6: Certifications, conformity
Conformity CE, CDRH
Certifications UL60950-1, CSA C22.2 No.60950-1
CAUTION
UL applications!
For UL applications, use is only permitted in Class 2 circuits in accordance with the NEC (Na-
tional Electric Code).
13.1.1 BPS without heating
CAUTION
UL applications!
For UL applications, use is only permitted in Class 2 circuits in accordance with the NEC (Na-
tional Electric Code).
Tab.13.7: Electrical equipment
Data specification Values/description
Interface type PROFINET-RT with integrated switch for BUSIN and BUS
OUT
Protocol: PROFINET RT communication
Conformance Class: B
Service USB interface Mini-B type USB2.0 socket
Switching input / switching output Two switching inputs/outputs
Functions are freely programmable via PROFINET interface
Switching input: 18…30VDC depending on supply voltage,
Imax. = 8mA
Switching output: 18…30VDC, depending on supply voltage,
Imax. = 60mA (short-circuit proof)
Switching inputs/outputs protected against polarity reversal!
PWR LED green Device ready (power on)
Operating voltage U
B
18…30VDC (Class 2, protection classIII)
Power consumption Max. 3.7W
Tab.13.8: Ambient temperature
Ambient temperature (operation) -5°C…+50°C
Ambient temperature (storage) -35°C…+70°C
