Leuze BPS 348i - Module 10 - Speed

Starting up the device – Basic configuration
Leuze electronic GmbH + Co. KG BPS 348i 80
Parameter Rel.
addr.
Data
type
Value
range
Default Unit Explanation
Metr. Inch
Error delay
(speed)
3.3 Bit 0…1 1 ------------- Speed in the case of an er-
ror:
0: OFF (immediately outputs
the value of the Speed in the
case of error parameter)
1: ON (outputs the last valid
speed for the configured er-
ror delay time)
Error delay time
(speed)
4…5 unsign
16 bit
10…4,
000
50 1ms Errors that occur are sup-
pressed for the configured
time, i.e., if no valid speed
can be ascertained in the
configured time, the last valid
speed is always output.
If the error persists after the
time elapses, the value of
the Speed in the case of er-
ror parameter is output.
8.4.12 Module10–Speed
Module ID:1010 with submodule ID:1
• The module is used to output the current speed in the desired resolution.
• The unit (metric or inch) is set via module1 (position value) and also applies to the speed. If module1
is not configured, the value is output with the default unit of measurement (metric). The sign of the
speed is dependent on the count direction selected in module1. With the default counting direction
(positive), a positive speed is output for movement towards larger tape values. Movement towards
smaller tape values results in negative speeds. Measurement value preparation averages all speed val-
ues calculated during the selected period (averaging) to yield a speed output value.
• The module contains parameters (with parameter data length of 2bytes) and input data (with consis-
tent input data length of 4bytes), but no output data.
Parameter Rel. addr. Data
type
Value
range
De-
fault
Unit Explanation
Metr. Inch
Speed resolution 0.0…0.2 Bit 1…5 1 mm/s (in/100)/s Resolution for the
speed value:
001=1: 1
010=2: 10
011=3: 100
100=4: 1000
101=5: Free resolu-
tion
Averaging 0.3…0.5 Bit 0…5 2 ------------- All calculated veloci-
ties are averaged over
the specified time:
000=0: No averaging
001=1: 2ms
010=2: 4ms
011=3: 8ms
100=4: 16ms
101=5: 32ms
