Leuze BPS 348i - Module 7 - Position Limit Value Range 1; Module 8 - Position Limit Value Range 2; Module 9 - Error Handling Procedures

Starting up the device – Basic configuration
Leuze electronic GmbH + Co. KG BPS 348i 78
Output data Rel.
addr.
Data
type
Value
range
Init
value
Unit Explanation
Metr. Inch
Acknowledge control
or marker barcode
0.2 Bit 0…1 0 ------------- With this bit, the acceptance
of the detected control or
marker barcode can be ac-
knowledged to the PLC.
Transition 0→1: Acknowl-
edgment
Acknowledge event
log
0.3 Bit 0…1 ------------- Deletes the event memory
from module 25 – device sta-
tus (input data):
128: Error
129: Warning
8.4.9 Module7–Position limit value range1
Module ID:1007 with submodule ID:1
• The module defines a position range with lower and upper limits. If the measured position value is out-
side of the configured range, the corresponding status bit is set in module6 and, if configured, an out-
put is set.
• The module contains parameters (with parameter data length of 8bytes), but no input data and no out-
put data.
Parameter Rel.
addr.
Data type Value range Default Unit Explanation
Metr. Inch
Lower pos. limit1 0…3 sign
32 bit
-10,000,000
…
+10,000,000
0 mm in/10
0
Lower position
limit.
Upper pos. limit1 4…7 sign
32 bit
-10,000,000
…
+10,000,000
0 mm in/10
0
Upper position
limit.
8.4.10 Module8–Position limit value range2
Module ID:1008 with submodule ID:1
• The module defines a position range with lower and upper limits. If the measured position value is out-
side of the configured range, the corresponding status bit is set in module6 and, if configured, an out-
put is set.
• The module contains parameters (with parameter data length of 8bytes), but no input data and no out-
put data.
Parameter Rel.
addr.
Data
type
Value range De-
fault
Unit Explanation
Metr. Inch
Lower pos. limit2 0…3 sign
32 bit
-10,000,000…
+10,000,000
0 mm in/100 Lower position
limit.
Upper pos. limit2 4…7 sign
32 bit
-10,000,000…
+10,000,000
0 mm in/100 Upper position
limit.
8.4.11 Module9–Error handling procedures
Module ID:1009 with submodule ID:1
• The module makes parameters available to handle any errors should they occur.
