Starting up the device – Basic configuration
Leuze electronic GmbH + Co. KG BPS 348i 77
Input data Rel.
addr.
Data
type
Value
range
Init
value
Unit Explanation
Metr. Inch
Temperature error 1.3 Bit 0…1 0 ------------ Signals that the maximum
permissible temperature has
been exceeded.
0: OK
1: Temperature error
Hardware defect 1.4 Bit 0…1 0 ------------ Signals a hardware defect.
0: OK
1: Hardware defect
Warning threshold
reading quality
1.5 Bit 0…1 0 ------------ Signals that the ascertained
reading quality has dropped
below the configured warning
threshold.
0: OK
1: Value less than limit
Error threshold read-
ing quality
1.6 Bit 0…1 0 ------------ Signals that the ascertained
reading quality has dropped
below the configured error
threshold.
0: OK
1: Value less than limit
Standby active 1.7 Bit 0…1 0 ------------ Signals an active standby.
0: No standby
1: Standby active
Output data Rel.
addr.
Data
type
Value
range
Init
value
Unit Explanation
Metr. Inch
Stopping/starting the
measurement
0.0 Bit 0…1 0 ------------- With this bit, the measure-
ment can be stopped and
restarted.
If the measurement is
stopped, the BPS only deac-
tivates the laser beam.
If the measurement is
restarted, measurement val-
ues are available again after
a few milliseconds.
0: Measurement active
1: Stop measurement
Activate/deactivate
standby
0.1 Bit 0…1 0 ------------- With this bit, the BPS can be
switched to standby; the
BPS deactivates laser beam
and motor.
If standby is then deacti-
vated, the motor must first
reach its nominal rotational
speed; as a result, it takes
several seconds before mea-
surement values are avail-
able again.
0: Not active
1: Activate
