Starting up the device – Basic configuration
Leuze electronic GmbH + Co. KG BPS 348i 76
Input data Rel.
addr.
Data
type
Value
range
Init
value
Unit Explanation
Metr. Inch
Measurement value
invalid
0.0 Bit 0…1 0 ------------ Signals that no valid measure-
ment value can be ascer-
tained.
0: Measurement value valid
1: Measurement value invalid
Measurement not ac-
tive
0.1 Bit 0…1 ------------ Signals an inactive measure-
ment.
0: Measurement active
1: Measurement not active
Preset active 0.2 Bit 0…1 0 ------------ Signals a position value out-
put with active preset.
0: No preset active
1: Preset active
Teach Preset toggle 0.3 Bit 0…1 0 ------------ This toggle bit changes its
state on each Teach Preset
event.
Lower position limit
value1
0.4 Bit 0…1 0 ------------ Signals that the value is less
than lower position limit1.
0: OK
1: Value less than limit
Upper position limit
value1
0.5 Bit 0…1 0 ------------ Signals that upper position
limit1 has been exceeded.
0: OK
1: Value greater than limit
Lower position limit
value2
0.6 Bit 0…1 0 ------------ Signals that the value is less
than lower position limit2.
0: OK
1: Value less than limit
Upper position limit
value2
0.7 Bit 0…1 0 ------------ Signals that upper position
limit2 has been exceeded.
0: OK
1: Value greater than limit
Control or marker
barcode detected
1.0 Bit 0…1 0 ------------ Signals a detected control or
marker barcode.
0: No marker
1: Marker detected
Control or marker
barcode toggle
1.1 Bit 1…5 0 ------------ This toggle bit changes its
state on each detected control
or marker barcode.
0, 1: New marker
Temperature warning 1.2 Bit 1…5 0 ------------ Signals that temperature is no
longer within the specified
temperature range.
0: OK
1: Temperature warning
